3-Screen Display High-Precision Digital Pressure Switch ISE7□/7□G
|
・It is possible to change the settings while checking the measured value.
・IO-Link ・Angled display Good visibility from various mounting positions ・Rotating display Display can rotate 336 degrees after installation ・Applicable fluid：Air, Non-corrosive gas, Non-flammable gas (ISE70/71) ：Liquid or gas that will not corrode materials of parts in contact with fluid (ISE7□G) |
|
| Other Data |
|---|
| Series | Flow characteristics 4/2→3/5（A/B→E） C［dm3/（s・bar）］ |
Flow characteristics 4/2→3/5（A/B→E） b |
|---|---|---|
| ISE70 | Positive pressure (For air) | 0 to 1MPa |
| ISE71 | Positive pressure (For air) | 0 to 1.6MPa |
| ISE70G | Positive pressure (For general fluids) | 0 to 1MPa |
| ISE75G | Positive pressure (For general fluids) | 0 to 2MPa |
| ISE76G | Positive pressure (For general fluids) | 0 to 5MPa |
| ISE77G | Positive pressure (For general fluids) | 0 to 10MPa |
3-Screen Display High-Precision Digital Pressure SwitchISE7□/7□G
| Series | Flow characteristics 4/2→3/5（A/B→E） C［dm3/（s・bar）］ |
Download |
|---|---|---|
| ISE70 | Positive pressure (For air) |
|
| ISE71 | Positive pressure (For air) |
|
| ISE70G | Positive pressure (For general fluids) |
|
| ISE75G | Positive pressure (For general fluids) |
|
| ISE76G | Positive pressure (For general fluids) |
|
| ISE77G | Positive pressure (For general fluids) |
|
■It is possible to change the settings while checking the measured value.
■Visualization of Settings
The sub screen (label) shows the item to be set.
■Angled display
Good visibility from various mounting positions
■Rotating display
■Simple 3-Step Setting
When the SET button is pressed and the set value (P_1) is being displayed, the set value (threshold value) can be set.
When the SET button is pressed and the hysteresis value (H_1) is being displayed, the hysteresis value can be set.
■NPN/PNP Switch Function
Both NPN and PNP are available.The number of stock items can be reduced.
■Other Sub Screen Display
The peak value, bottom value, or both values can be displayed on one screen!
* Peak and bottom values are maintained even if the power supply is cut.
■Convenient Functions
■3 Setting Modes
Select the setting mode that best meets your needs.
■IO-Link Compatible
Visualization of operation/equipment status/Remote monitoring and control by communication
■Introduction of Series
■For General Fluids: Remote Type Variations
■Select either the integrated type or the remote type according to the application.
